These Aluminium Backup are used to hold the cable armour in conjunction with the worm drive clamp in straight through joints and cable terminations.
| Code | D (mm)±0.5 mm | L (mm)±2 mm | T(mm)±0.1mm |
|---|---|---|---|
| PBRAL-PS-023-13-20 | 13 | 20 | 1 |
| PBRAL-PS-023-19-25 | 19 | 25 | 1.5 |
| PBRAL-PS-023-22-30 | 22 | 30 | 2 |
| PBRAL-PS-023-27-30 | 27 | 30 | 1.5 |
| PBRAL-PS-023-32-30 | 32 | 30 | 2 |
| PBRAL-PS-023-42-30 | 42 | 30 | 12 |
| PBRAL-PS-023-44-40 | 44 | 40 | 2 |
| PBRAL-PS-023-54-30 | 54 | 30 | 2 |
| PBRAL-PS-023-58-30 | 58 | 30 | 2 |
| PBRAL-PS-023-60-50 | 60 | 50 | 2 |
| PBRAL-PS-023-60-50 | 60 | 50 | 2 |
| PBRAL-PS-023-70-60 | 70 | 60 | 2 |
| PBRAL-PS-023-72-30 | 72 | 30 | 2 |
| PBRAL-PS-023-22-60 | 22 | 60 | 2 |
| PBRAL-PS-023-32-60 | 32 | 60 | 2 |
| PBRAL-PS-023-42-60 | 42 | 60 | 2 |
| PBRAL-PS-023-54-60 | 54 | 60 | 2 |
| PBRAL-PS-023-58-60 | 58 | 60 | 2 |
| PBRAL-PS-023-66-60 | 66 | 60 | 2 |
| PBRAL-PS-023-72-60 | 72 | 60 | 2 |
| PBRAL-PS-023-77-60 | 77 | 60 | 2 |
| PBRAL-PS-023-85-60 | 85 | 60 | 2 |
| PBRAL-PS-023-90-60 | 90 | 60 | 2 |
| PBRAL-PS-023-95-60 | 95 | 50 | 2 |
| PBRAL-PS-023-100-60 | 100 | 60 | 2 |
| PBRAL-PS-023-105-60 | 105 | 60 | 2 |
| PBRAL-PS-023-110-60 | 110 | 60 | 2 |
